Key Features
- 1Achieve 99.99% filtration efficiency for clean compressed air. 2、Minimize maintenance with a fully automatic condensate drain. 3、Integrate easily into various pneumatic systems. 4、Ensure durability with die-cast zinc and borosilicate fibre. 5、Meet ISO 8573-1:2010 and RoHS compliance standards.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Series | D | Size | Mini |
| Structural design | Fiber filter | Grade of filtration | 1μm |
| Condensate drain | Manually rotating | Symbol | 00991543 |
| Operating pressure | 1bar 16bar | Operating medium | Compressed air as per ISO 8573-1:2010 [6:8:4] Inert gas |
| Air quality class at the output | Compressed air as per ISO 8573-1:2010 [5:7:3] Inert gas | Filter efficiency | 99.99% |
| Max. condensate volume | 22ml | Bowl guard | Metal bowl guard |
| Corrosion resistance class (CRC) | 2 - Moderate corrosion stress | LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Temperature of medium | 1.5°C 60°C | Ambient temperature | -10°C 60°C |
| Storage temperature | -10°C 60°C | Residual oil content | 0.5mg/m3 |
| Differential pressure display | Visual display | Type of mounting | Optionally: Line installation With accessories |
| Mounting position | Vertical +/- 5° | Pneumatic connection 1 | Sub-base |
| Pneumatic connection 2 | Sub-base | Housing material | Die-cast zinc |
| Compressed air filter material | Borosilicate fiber | Material of bowl | PC |
| Note on materials | RoHS-compliant | Product weight | 283g |
| Manufacturer ID | 532811 |
Specifications may be subject to change without notice
