Key Features
- 1Deliver up to 11,000 L/min flow for high-demand applications. 2、Select from 0.5-7 bar or 0.5-12 bar pressure regulation ranges. 3、Ensure air purity with 5 µm or 40 µm filter cartridge options. 4、Choose manual, semi-, or fully automatic condensate drainage. 5、Rely on a durable metal bowl guard and locking rotary knob.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Size | Maxi | Series | D |
| Actuator lock | Rotary knob with detent | Mounting position | Vertical +/- 5° |
| Grade of filtration | 40μm | Condensate drain | Manually rotating |
| Structural design | Filter regulator without pressure gauge | Max. condensate volume | 79.968ml |
| Bowl guard | Metal bowl guard | Symbol | 00991589 |
| Pressure gauge | G1/4 prepared | Operating pressure | 0.951bar 16.547bar |
| Pressure regulation range | 0.476bar 12.411bar | Max. pressure hysteresis | 0.414bar |
| Standard nominal flow rate | 43156.78l/min | Operating medium | Compressed air as per ISO 8573-1:2010 [-:9:-] Inert gas |
| Information on operating and pilot media | Operation with oil lubrication possible (required for further use) | Corrosion resistance class (CRC) | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L | Storage temperature | -10°C 60°C |
| Air quality class at the output | Compressed air as per ISO 8573-1:2010 [7:8:4] Inert gas | Temperature of medium | -10°C 60°C |
| Ambient temperature | -10°C 60°C | Product weight | 1289.925g |
| Type of mounting | With accessories | Note on materials | RoHS-compliant |
| Housing material | Die-cast zinc | Material of bowl | PC |
| Manufacturer ID | 546437 |
Specifications may be subject to change without notice
