Key Features
- 1Ensure minimal pressure loss for peak pneumatic system performance. 2、Eliminate manual intervention with automatic condensate drainage. 3、Save valuable space with a compact, inline design. 4、Remove harmful water vapor and dust contaminants. 5、Install easily using standard NPT thread connections.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Size | Midi | Series | D |
| Actuator lock | Rotary knob with detent | Mounting position | Vertical +/- 5° |
| Grade of filtration | 40μm | Condensate drain | Manually rotating |
| Structural design | Filter regulator without pressure gauge | Max. condensate volume | 42.983ml |
| Bowl guard | Metal bowl guard | Pressure gauge | G1/4 prepared |
| Operating pressure | 0.951bar 16.547bar | Pressure regulation range | 0.476bar 12.411bar |
| Max. pressure hysteresis | 0.207bar | Standard nominal flow rate | 13792.37l/min |
| Operating medium | Compressed air as per ISO 8573-1:2010 [-:9:-] Inert gas | Information on operating and pilot media | Operation with oil lubrication possible (required for further use) |
| Corrosion resistance class (CRC) | 2 - Moderate corrosion stress | LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Storage temperature | -10°C 60°C | Air quality class at the output | Compressed air as per ISO 8573-1:2010 [7:8:4] Inert gas |
| Temperature of medium | -10°C 60°C | Ambient temperature | -10°C 60°C |
| Product weight | 912.87g | Type of mounting | Optionally: Line installation With accessories |
| Note on materials | RoHS-compliant | Housing material | Die-cast zinc |
| Material of bowl | PC | Manufacturer ID | 546425 |
Specifications may be subject to change without notice
