ms12-mv
Product ID:10271
Updated: 2026/4/3
Key Features
- 1Ensure reliable compressed air treatment in industrial settings. 2、Feature moderate corrosion resistance (CRC 2) for durability. 3、Operate within a -10 to 60°C temperature range. 4、Construct with RoHS-compliant, environmentally friendly materials. 5、Integrate easily into complex, modular pneumatic systems.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Size | 12 | Series | MS |
| Corrosion resistance class (CRC) | 2 - Moderate corrosion stress | LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Storage temperature | -10°C 60°C | Temperature of medium | -10°C 60°C |
| Product weight | 500g | Note on materials | RoHS-compliant |
| Seals material | NBR | Plate material | Die-cast aluminum |
| Material of screws | Steel | Manufacturer ID | 537134 |
Specifications may be subject to change without notice
