ms4-mv-ex
Product ID:10719
Updated: 2026/4/3
Key Features
- 1Ensure reliable connections in high-performance industrial applications. 2、Resist moderate corrosion in demanding environments. 3、Operate across a wide -10°C to 60°C temperature range. 4、Construct with durable POM, NBR, and steel materials. 5、Meet eco-standards with full RoHS compliance.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Size | 4 | Series | MS |
| Corrosion resistance class (CRC) | 2 - Moderate corrosion stress | LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Temperature of medium | -10°C 60°C | Product weight | 36g |
| Note on materials | RoHS-compliant | Seals material | NBR |
| Module connector material | POM Steel | Material of screws | Steel |
| Manufacturer ID | 541553 |
Specifications may be subject to change without notice
