ms6-frm-1/2-y
Product ID:9260
Updated: 2026/4/3
Key Features
- 1Branch compressed air efficiently with four G1/2 ports. 2、Maximize space using a compact 62 mm grid dimension. 3、Connect various lines with G1/4, G3/8, and G1/2 female threads. 4、Prevent backflow using the integrated non-return function. 5、Ensure quality with ISO 1179-1 and ISO 228-1 standards.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Mounting position | Any | Structural design | Branching module |
| Symbol | 00995602 | Operating pressure | 0bar 12bar |
| Standard nominal flow rate in main flow direction 1 -> 2 | 14700l/min | Standard nominal flow rate outlet at top | 4400l/min |
| Standard nominal flow rate outlet down | 4600l/min | Operating voltage range AC | 0V 250V |
| DC operating voltage range | 0V 125V | Operating medium | Compressed air as per ISO 8573-1:2010 [7:4:4] Inert gas |
| Information on operating and pilot media | Operation with oil lubrication possible (required for further use) | Corrosion resistance class (CRC) | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L | Storage temperature | -10°C 60°C |
| For use in the food industry | See supplementary material information | Temperature of medium | -10°C 60°C |
| Ambient temperature | -10°C 60°C | Product weight | 736g |
| Pneumatic connection 1 | G1/2 | Pneumatic connection 2 | G1/2 |
| Pneumatic connection 3 | G1/2 | Pneumatic connection 4 | G1/2 |
| Note on materials | RoHS-compliant | Housing material | Die-cast aluminum |
| Manufacturer ID | 529854 |
Specifications may be subject to change without notice
