ms6-wp-f1a
Product ID:287
Updated: 2026/4/3
Key Features
- 1Achieve CRC 2 corrosion resistance for moderate stress environments. 2、Install in-line or via bracket for flexible mounting. 3、Utilize RoHS-compliant materials for regulatory adherence. 4、Integrate the 76-gram compact design easily. 5、Apply in diverse pneumatic applications like battery production.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Size | 6 | Series | MS |
| Corrosion resistance class (CRC) | 2 - Moderate corrosion stress | LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Suitability for the production of Li-ion batteries | Metals with more than 1% by mass of copper, zinc or nickel are excluded from use.The exceptions are nickel in steel, chemically nickel-plated surfaces, circuit boards, cables, electrical plug connectors and coils | Temperature of medium | -10°C 60°C |
| Product weight | 76g | Note on materials | RoHS-compliant |
| Seals material | NBR | Module connector material | POM High-alloy stainless steel |
| Material of screws | High-alloy stainless steel | Bracket material | Die-cast aluminum |
| Manufacturer ID | 8176698 |
Specifications may be subject to change without notice
