ms9-12-armv
Product ID:11968
Updated: 2026/4/3
Key Features
- 1Ensure reliable performance with CRC 2 moderate corrosion resistance. 2、Adhere to environmental standards with RoHS compliance. 3、Operate in diverse conditions with a -10°C to 60°C range. 4、Meet high-quality standards with LABS and VDMA24364 conformity. 5、Provide robust connectivity using durable die-cast aluminum and steel.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Size | 9 12 | Series | MS |
| Corrosion resistance class (CRC) | 2 - Moderate corrosion stress | LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Temperature of medium | -10°C 60°C | Product weight | 990g |
| Note on materials | RoHS-compliant | Material of sub-base | Die-cast aluminum |
| Seals material | NBR | Module connector material | Die-cast aluminum |
| Material of screws | Steel | Manufacturer ID | 552953 |
Specifications may be subject to change without notice
