msfg-12-od
Product ID:8152
Updated: 2026/4/3
Key Features
- 1Operate at 12 V DC with 4.1 W power and a 10 ms pick-up time for fast response. 2、Construct with Duroplast, copper, and steel for durability in -5°C to 40°C. 3、Protect against dust and water with an IP65 rating for reliable use. 4、Connect easily via 3-pin plug following the Festo MSSD-F standard. 5、Comply with RoHS and LABS (PWIS) standards for safety and environment.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Mounting position | Any | Switching position indication | no |
| Min. pick-up time | 10ms | Duty cycle | 100% |
| Coil characteristics | 12 V DC: 4.1 W | Permissible voltage fluctuations | +/- 10 % |
| LABS (PWIS) conformity | VDMA24364-C1-L | Degree of protection | IP65 |
| Ambient temperature | -5°C 40°C | Max. tightening torque of socket | 0.4Nm |
| Product weight | 55g | Electrical connection | 3-pin Plug flags with connection diagram as per Festo standard for MSSD-F |
| Type of mounting | With knurled nut | Note on materials | RoHS-compliant |
| Solenoid coil material | Duroplast Copper Steel | Material of winding | Copper |
| Manufacturer ID | 34410 |
Specifications may be subject to change without notice
