msfw-48-50/60-od
Product ID:8157
Updated: 2026/7/4
Key Features
- 1Ensure reliable performance from -5°C to +40°C.
- 2Mount flexibly with a 360° rotatable knurled nut.
- 3Withstand harsh conditions with an IP65 protection rating.
- 4Handle power efficiently at 48V AC and 4.1W.
- 5Receive support with comprehensive warranty and documentation.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Mounting position | Any | Switching position indication | no |
| Min. pick-up time | 10ms | Duty cycle | 100% |
| Power factor cos {phi} | 0.7 | Coil characteristics | 48 V AC: 50/60 Hz, initial power 9.0 VA, holding power 7.0 VA |
| Permissible frequency fluctuations | +/- 5% | Permissible voltage fluctuations | +/- 10 % |
| LABS (PWIS) conformity | VDMA24364-C1-L | Degree of protection | IP65 |
| Ambient temperature | -5°C 40°C | Max. tightening torque of socket | 0.4Nm |
| Product weight | 55g | Electrical connection | 3-pin Plug flags with connection diagram as per Festo standard for MSSD-F |
| Type of mounting | With knurled nut | Note on materials | RoHS-compliant |
| Solenoid coil material | Duroplast Copper Steel | Material of winding | Copper |
| Manufacturer ID | 34418 |
Specifications may be subject to change without notice
