mssd-eb-m12
Product ID:10497
Updated: 2026/4/3
Key Features
- 1Ensure secure electrical connections for pneumatic systems. 2、Mount flexibly via central M2.5 screw on valves. 3、Achieve IP65 protection against dust and water ingress. 4、Operate across a 12-24V DC/AC voltage range. 5、Construct with durable PA housing and HNBR seals.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Contact durability | 50 | Type of mounting | On air solenoid valve with M2.5 central screw |
| Mounting position | Any | Product weight | 11g |
| Electrical connection | 3-pin Socket, angled Form C as per DIN EN 175301-803 Rectangular design | Cable fitting | M12 |
| Approved cable diameter | 4mm 6mm | Connection cross section | 1.5mm2 |
| Degree of protection | IP65 as per IEC 60529 | Ambient temperature | -40°C 125°C |
| LABS (PWIS) conformity | VDMA24364-B2-L | Housing material | PA-reinforced |
| Seals material | HNBR | Manufacturer ID | 539712 |
Specifications may be subject to change without notice
