nebv-h1g2-kn-5-n-le2
Product ID:13382
Updated: 2026/4/3
Key Features
- 1Ensure reliable connections with a 3-pin angular plug and snap-locking design. 2、Extend your reach using the included 5-meter standard cable length. 3、Benefit from durable construction featuring POM housing and tin-plated contacts. 4、Protect against harsh environments with a robust IP40 degree of protection. 5、Meet safety standards with compliance to EU RoHS Directive and CE marking.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Cable designation | Without label holder | Mounting position | Any |
| Product weight | 31g | Electrical connection 1, function | Field device end |
| Electrical connection 1, design | Rectangular | Electrical connection 1, connection type | Socket |
| Electrical connection 1, cable outlet | Straight | Electrical connection 1, connection technology | Connection diagram H |
| Electrical connection 1, number of pins/wires | 3 | Electrical connection 1, occupied pins/wires | 2 |
| Electrical connection 1, type of mounting | Snap-locking | Electrical connection for input 1, connection pattern | 00995622 |
| Electrical connection 2, function | Control side | Electrical connection 2, connection type | 2x single wires |
| Electrical connection 2, connection technology | Open end | Electrical connection 2, number of pins/wires | 2 |
| Electrical connection 2, occupied pins/wires | 2 | DC operating voltage range | 0V 60V |
| Current rating at 40° C | 3A | Cable length | 5m |
| Cable characteristic | Standard | Cable diameter | 1.3mm |
| Cable design | 2 x 0.14 mm2 | Nominal conductor cross section | 0.14mm2 |
| Wire ends | Cut off bluntly | Degree of protection | IP40 |
| Note on degree of protection | In mounted state | Ambient temperature | -5°C 60°C |
| CE marking (see declaration of conformity) | As per EU RoHS directive | UKCA marking (see declaration of conformity) | To UK RoHS instructions |
| LABS (PWIS) conformity | VDMA24364-B2-L | Note on materials | RoHS-compliant |
| Housing material | POM | Housing colour | Black |
| Material of pin contacts | Copper alloy Tin-plated | Insulating sheath material | PVC |
| Manufacturer ID | 566657 |
Specifications may be subject to change without notice
