necu-l3g8-c1
Product ID:13214
Updated: 2026/4/3
Key Features
- 1Secure connections with 8-pin spring-loaded terminals. 2、Handle DC voltage from 0-30V for versatile use. 3、Deliver reliable 12A current at 40°C. 4、Mount in any position for flexible installation. 5、Use RoHS-compliant, corrosion-resistant materials.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Contact durability | 100 | Mounting position | Any |
| Product weight | 36g | Electrical connection | 8-pin Spring-loaded terminal Plug, straight |
| DC operating voltage range | 0V 30V | Current rating at 40° C | 12A |
| Surge resistance | 4kV | Connection cross section | 0.2mm2 2.5mm2 |
| Ambient temperature | -40°C 85°C | LABS (PWIS) conformity | VDMA24364-B2-L |
| Note on materials | RoHS-compliant | Contamination level | 3 |
| Corrosion resistance class (CRC) | 2 - Moderate corrosion stress | Housing material | PA |
| Housing colour | Black | Material of pin contacts | Copper alloy Tin-plated |
| Manufacturer ID | 565712 |
Specifications may be subject to change without notice
