necu-l3g8-c2-is
Product ID:13211
Updated: 2026/4/3
Key Features
- 1Choose optional mounting positions for flexible installation. 2、Handle 12A current at 40°C for high-power applications. 3、Resist 4KV surges for superior electrical protection. 4、Operate within a 0-30V DC range for versatile use. 5、Utilize PA material and tin-plated contacts for durability.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Explosion prevention and protection | Observe the information on the certificate Zone 1 (ATEX) Zone 2 (ATEX) Zone 21 (ATEX) Zone 22 (ATEX) | Contact durability | 100 |
| Mounting position | Any | Product weight | 55.5g |
| Electrical connection | 8-pin Screw terminal Plug, straight | DC operating voltage range | 0V 30V |
| Current rating at 40° C | 12A | Surge resistance | 4kV |
| Connection cross section | 0.2mm2 2.5mm2 | Ambient temperature | -40°C 85°C |
| LABS (PWIS) conformity | VDMA24364-B2-L | Note on materials | RoHS-compliant |
| Contamination level | 3 | Corrosion resistance class (CRC) | 2 - Moderate corrosion stress |
| Housing material | PA | Housing colour | Blue |
| Material of pin contacts | Copper alloy Tin-plated | Manufacturer ID | 565709 |
Specifications may be subject to change without notice
