necu-m-s-b12g5-c2-pb
Product ID:706
Updated: 2026/4/3
Key Features
- 1Meet EN 61076-2-101 and EN 61984 standards for reliable connections. 2、Feature an M12x1 5-pin B-coded shieldable socket. 3、Support 0-60V AC/DC for versatile application use. 4、Provide 1.5 kV surge resistance and IP67 environmental protection. 5、Construct with die-cast zinc and gold-plated contacts for durability.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Based on norm | EN 61076-2-101 EN 61984 | Product weight | 46.1g |
| Electrical connection 1 | Straight plug, M12x1, 5-pin, B-coded, shieldable | Plug coding | B |
| Electrical connection 2 | Screw terminal, can be shielded | DC operating voltage range | 0V 60V |
| Operating voltage range AC | 0V 60V | Current rating at 40° C | 4A |
| Surge resistance | 1.5kV | Transmission characteristics | DIN EN 50173/CAT 5 |
| Approved cable diameter | 6mm 8mm | Connection cross section | 0.14mm2 0.75mm2 |
| Degree of protection | IP67 | Ambient temperature | -25°C 85°C |
| CE marking (see declaration of conformity) | As per EU low voltage directive | LABS (PWIS) conformity | VDMA24364-B2-L |
| Note on materials | RoHS-compliant | Contamination level | 3 |
| Corrosion resistance class (CRC) | 1 - Low corrosion stress | Housing material | Die-cast zinc Nickel-plated |
| Material of pin contacts | Brass Gold-plated | Manufacturer ID | 1066354 |
Specifications may be subject to change without notice
