qsmk-m5-4
Product ID:2631
Updated: 2026/7/6
Key Features
- 1The Festo QSML-M5-4 push-in L-fitting ensures quick and reliable connections with its push-pull principle, making it ideal for various industrial tasks.
- 2With a corrosion resistance class of CRC 1, this fitting is designed to withstand low corrosion stress, ensuring durability in demanding environments.
- 3Constructed from highly resistant materials like PBT for the body, POM for the release ring, and high-alloy stainless steel for the tube retaining claw, this fitting offers maximum flexibility.
- 4The optimized bending radius of the QSML-M5-4 makes it easy to install, reducing installation time and effort in your pneumatic systems.
- 5Operating within a temperature range of -10 °C to 80 °C and pressure range of -0.95 bar to 6 bar, this fitting meets all requirements for standard applications with increased pressure and temperature ranges.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Size | Standard | Nominal width | 1.4mm |
| Approved tubing type | PAN- PAN-MF- PAN-R- PAN-V0- PEN- PFAN- PLN- PTFEN- PUN- PUN-CM- PUN-DUO- PUN-H- PUN-H-DUO- PUN-S- PUN-S-DUO- PUN-V0- | Tubing insertion depth | 12.7mm |
| Type of seal on screwed plug | Sealing ring | Mounting position | Any |
| Design | Straight design | Pack size | 1 |
| Structural design | Push-pull principle | Operating pressure for entire temperature range | -13.775psi 87psi |
| Temperature-dependent operating pressure | -13.775psi 203psi | Operating medium | Compressed air as per ISO 8573-1:2010 [7:-:-] |
| Information on operating and pilot media | Operation with oil lubrication possible | Corrosion resistance class (CRC) | 1 - Low corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L | Ambient temperature | -10°C 80°C |
| Nominal tightening torque | 1.2Nm | Tolerance for nominal tightening torque | ± 20% |
| Product weight | 7.1g | Type of mounting | External hexagon, AF 8 |
| Pneumatic connection 1 | External thread M5 | Pneumatic connection 2 | for pneumatic tubing outside diameter 4 mm |
| Releasing ring color | Blue | Note on materials | RoHS-compliant |
| Housing material | Brass, nickel-plated | Releasing ring material | POM |
| Material of tubing seal | NBR | Material of tube retaining claw | High-alloy stainless steel |
| Manufacturer ID | 153291 |
Specifications may be subject to change without notice
