qsp10-6
Product ID:5154
Updated: 2026/7/5
Key Features
- 1Ensure leak-free operations with an O-ring seal on the screw-in stud.
- 2Operate reliably within a wide 0 to 60 °C temperature range.
- 3Simplify assembly using the straight design and push-pull principle.
- 4Handle diverse applications with a -0.95 to 10 bar operating pressure.
- 5Meet environmental standards via the RoHS-compliant nickel-plated housing.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Type of seal on screwed plug | O-ring | Mounting position | Any |
| Design | Straight design | Pack size | 10 |
| Structural design | Push-pull principle | Operating pressure for entire temperature range | -13.775psi 145psi |
| Operating medium | Compressed air as per ISO 8573-1:2010 [7:-:-] | Information on operating and pilot media | Operation with oil lubrication possible |
| Corrosion resistance class (CRC) | 1 - Low corrosion stress | LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Ambient temperature | 0°C 60°C | Type of mounting | Mounting pin |
| Pneumatic connection 1 | Cartridge 10 mm | Pneumatic connection 2 | for pneumatic tubing outside diameter 6 mm |
| Releasing ring color | Blue | Note on materials | RoHS-compliant |
| Housing material | Brass, nickel-plated | Manufacturer ID | 172973 |
Specifications may be subject to change without notice
