sdbf-fds-1l-nu-k-n-m12
Product ID:395
Updated: 2026/4/3
Key Features
- 1Utilize magneto-resistive technology for precise position measurement. 2、Achieve fast response with 1.5 µs switch-on and 0.5 µs switch-off times. 3、Withstand harsh conditions via robust block design and IP67 protection. 4、Integrate easily using the standard M12x1 A-coded connector. 5、Monitor operational status visually with the integrated LED indicator.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Design | Block design | Note on materials | RoHS-compliant |
| Measured variable | Position | Measuring principle | Magneto-resistive |
| Ambient temperature | -20°C 80°C | Ambient temperature Fahrenheit | -4°F 176°F |
| Switching output | NPN | Switching element function | N/O contact |
| On time | 0.0015ms | Switch-off time | 5.0E-4ms |
| Max. output current | 1000mA | Max. switching capacity DC | 24W |
| Voltage drop | 0.5V | Short-circuit protection | no |
| DC operating voltage range | 6V 24V | Reverse polarity protection | no |
| Electrical connection 1, connection type | Cable with socket | Electrical connection 1, connection technology | M12x1 A-coded as per EN 61076-2-101 |
| Electrical connection 1, number of pins/wires | 3 | Connection outlet orientation | Transverse |
| Color cable sheath | Gray | Material of cable sheath | PVC |
| Type of mounting | Clamped | Mounting position | Any |
| Housing colour | Black | Housing material | PA |
| Switching status indication | LED | Ambient temperature with flexible cable installation | -20°C 80°C |
| Degree of protection | IP67 NEMA 4 | LABS (PWIS) conformity | VDMA24364 zone III |
| Manufacturer ID | 8161170 |
