sde5-d10-o-q4-p-m8
Product ID:9054
Updated: 2026/7/4
Key Features
- 1Measure pressure accurately up to 10 bar.
- 2Ensure reliable operation in harsh industrial environments.
- 3Integrate seamlessly with QS-4 and PNP systems.
- 4Meet EU EMC and RoHS compliance standards.
- 5Simplify setup with a standardized pneumatic connection.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Symbol | 00991164 | Certification | RCM compliance mark c UL us - Recognized (OL) |
| CE marking (see declaration of conformity) | As per EU EMC directive As per EU RoHS directive | UKCA marking (see declaration of conformity) | To UK instructions for EMC To UK RoHS instructions |
| Note on materials | RoHS-compliant | Measured variable | Relative pressure |
| Method of measurement | Piezoresistive pressure sensor | Pressure measuring range initial value | 0bar |
| Pressure measuring range end value | 10bar | Operating medium | Compressed air as per ISO 8573-1:2010 [7:4:4] |
| Information on operating and pilot media | Operation with oil lubrication possible | Temperature of medium | 0°C 50°C |
| Ambient temperature | 0°C 50°C | Repetition accuracy in ± %FS | 0.3%FS |
| Temperature co-efficient in ± %FS/K | 0.05%FS/K | Switching output | PNP |
| Switching function | Threshold value with fixed hysteresis | Switching element function | N/O contact |
| Max. output current | 100mA | Short-circuit protection | yes |
| DC operating voltage range | 15V 30V | Reverse polarity protection | for all electrical connections |
| Electrical connection | 3-pin M8x1 Plug as per EN 60947-5-2 Round design | Type of mounting | With accessories |
| Mounting position | Any | Pneumatic connection | QS-4 |
| Product weight | 19g | Housing material | PA POM |
| Switching status indication | LED yellow | Setting range threshold value | 0% 100% |
| Degree of protection | IP40 | Corrosion resistance class (CRC) | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L | Cleanroom class | Class 4 according to ISO 14644-1 |
| Manufacturer ID | 527463 |
Specifications may be subject to change without notice
