Key Features
- 1Achieve 0.2 mm repeat accuracy for precise measurements.
- 2Operate reliably from -20°C to 60°C with magnetic reed technology.
- 3Withstand harsh conditions with an IP67 protection rating.
- 4Install flexibly in any position thanks to its round design.
- 5Meet DIN EN 60947-5-2, RCM, CE, and UKCA standards for compliance.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Design | Round | Conforms to standard | DIN EN 60947-5-2 |
| Symbol | 00992153 | Certification | RCM compliance mark |
| CE marking (see declaration of conformity) | As per EU EMC directive As per EU low voltage directive As per EU RoHS directive | UKCA marking (see declaration of conformity) | To UK instructions for EMC To UK RoHS instructions To UK instructions for electrical equipment |
| Measuring principle | Magnetic reed | Ambient temperature | -20°C 60°C |
| Repetition accuracy | 0.2mm | Switching output | Contact-based, bipolar Without LED function |
| Switching element function | N/O contact | On time | 2ms |
| Switch-off time | 0.05ms | Max. switching frequency | 500Hz |
| Max. output current AC | 250mA | Max. output current DC | 120mA |
| Min. switching capacity AC | 10VA | Max. switching capacity DC | 10W |
| Voltage drop | 4.5V | Short-circuit protection | no |
| Overload protection | Not available | Operating voltage range AC | 12V 250V |
| DC operating voltage range | 12V 250V | Reverse polarity protection | no |
| Electrical connection 1, connection type | Cable | Electrical connection 1, connection technology | Open end |
| Electrical connection 1, number of pins/wires | 2 | Connection outlet orientation | Longitudinal |
| Cable length | 2.5m | Material of cable sheath | PVC |
| Type of mounting | With accessories | Tightening torque | 0.8Nm |
| Mounting position | Any | Product weight | 70g |
| Housing material | PET TPE-O | Switching status indication | LED yellow |
| Degree of protection | IP67 | Surge resistance | 4kV |
| LABS (PWIS) conformity | VDMA24364-B2-L | Contamination level | 3 |
| Manufacturer ID | 150011 |
Specifications may be subject to change without notice
