vaba-s6-1-pt
Product ID:449
Updated: 2026/4/3
Key Features
- 1Ensure safe operation with reverse polarity and separate PS/PL protection. 2、Control up to 16 valve positions and 32 solenoid coils efficiently. 3、Reduce power consumption with 24V DC and 30 mA typical current. 4、Achieve fast data transfer via IO-Link V1.1 with a 3.2 ms cycle. 5、Deploy in corrosive environments with CRC 2 and PWIS compliant materials.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Reverse polarity protection | Separate for Power System (PS) and Power Load (PL) | Max. no. of valve positions | 16 |
| Max. no. of solenoid coils | 32 | Baud rate | 38.4 kbps |
| Intrinsic current consumption at nominal operating voltage for electronics/sensors | Typically 30 mA | Intrinsic current consumption at nominal operating voltage load | Typically 30 mA |
| Nominal operating voltage DC | 24V | Residual ripple | 4 Vss |
| Corrosion resistance class (CRC) | 2 - Moderate corrosion stress | LABS (PWIS) conformity | VDMA24364-B2-L |
| Product weight | 690g | IO-Link?, Connection technology | Device, 5-pin |
| IO-Link?, protocol version | Device V 1.1 | IO-Link?, communication mode | COM2 (38,4 kBd) |
| IO-Link?, port class | Device B | IO-Link?, number of ports | Device 1 |
| IO-Link?, process data width OUT | Device 1-4 byte | IO-Link?, minimum cycle time | Device 3.2 ms |
| Max. cable length | 20 m | Communication types | IO-Link? |
| Nominal conductor cross section | 1mm2 | Note on materials | RoHS-compliant |
| Cover material | Die-cast aluminum | Manufacturer ID | 8152353 |
Specifications may be subject to change without notice
