vabd-d3-l-gn12
Product ID:285
Updated: 2026/4/3
Key Features
- 1Operate reliably within a 0 to 12 bar pressure range for safe pneumatic systems. 2、Install flexibly with optional mounting positions in various industrial settings. 3、Meet ATEX Zone 1 and 2 standards for safety in hazardous environments. 4、Integrate seamlessly into Festo's range of pneumatic valves and manifolds. 5、Ensure optimal performance in high-pressure pneumatic applications.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Mounting position | Any | Symbol | 00991455 |
| Operating pressure | 0bar 12bar | Explosion prevention and protection | Zone 1 (ATEX) Zone 2 (ATEX) Zone 21 (ATEX) Zone 22 (ATEX) |
| Operating medium | Compressed air as per ISO 8573-1:2010 [7:-:-] | LABS (PWIS) conformity | VDMA24364 zone III |
| Degree of protection | IP54 | Ambient temperature | -50°C 60°C |
| Product weight | 14g | Type of mounting | Screw-in With external thread |
| Note on materials | RoHS-compliant | Vent screw material | HP PA 12 |
| Manufacturer ID | 8177961 |
Specifications may be subject to change without notice
