vabd-d3-sn-n12
Product ID:8250
Updated: 2026/4/3
Key Features
- 1Ensure safety in ATEX Zone 1 and 2 hazardous environments. 2、Protect pneumatic systems from hazardous gases reliably. 3、Minimize downtime with durable, long-service-life design. 4、Reduce operational costs through minimal maintenance needs. 5、Integrate easily into existing systems with a compact form.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Mounting position | Any | Symbol | 00991455 |
| Operating pressure | 0bar 12bar | Explosion prevention and protection | Zone 1 (ATEX) Zone 2 (ATEX) Zone 21 (ATEX) Zone 22 (ATEX) |
| Operating medium | Compressed air as per ISO 8573-1:2010 [7:-:-] | LABS (PWIS) conformity | VDMA24364 zone III |
| Degree of protection | IP65 | Ambient temperature | -50°C 60°C |
| Type of mounting | Screw-in With external thread | Note on materials | RoHS-compliant |
| Seals material | EPDM | Vent screw material | PA |
| Manufacturer ID | 3535104 |
Specifications may be subject to change without notice
