vabd-s1-1-p2-c
Product ID:15362
Updated: 2026/4/3
Key Features
- 1Ensure precise duct separation with exhaust air function via throttle plate. 2、Operate effectively from -10°C to 50°C and up to 10 bar pressure. 3、Handle versatile pneumatic and vacuum applications reliably. 4、Meet EU low voltage directive and RoHS compliance standards. 5、Utilize durable steel and NBR construction weighing only 70 grams.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Exhaust air function | Via throttle plate | Based on norm | ISO 5599-1 |
| Operating pressure | 0bar 10bar | Suitability for vacuum | yes |
| CE marking (see declaration of conformity) | As per EU low voltage directive | Operating medium | Compressed air as per ISO 8573-1:2010 [7:4:4] |
| Information on operating and pilot media | Operation with oil lubrication possible (required for further use) | Corrosion resistance class (CRC) | 0 - No corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L | Storage temperature | -20°C 60°C |
| Temperature of medium | -10°C 50°C | Pilot medium | Compressed air as per ISO 8573-1:2010 [7:4:4] |
| Ambient temperature | -10°C 50°C | Product weight | 70g |
| Note on materials | RoHS-compliant | Separator plate material | Steel NBR |
| Manufacturer ID | 8029439 |
Specifications may be subject to change without notice
