vabf-p5-p1a3-g14
Product ID:15002
Updated: 2026/4/3
Key Features
- 1Withstand moderate corrosion stress with a class 2 rating. 2、Ensure environmental compliance with RoHS directive. 3、Construct durable performance using NBR O-rings and aluminum. 4、Integrate easily into systems with a compact 61g design. 5、Supply pressure zones from 0 to 0.8 MPa versatilely.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Corrosion resistance class (CRC) | 2 - Moderate corrosion stress | LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Product weight | 61g | Note on materials | RoHS-compliant |
| O-ring material | NBR | Plate material | Wrought aluminum alloy |
| Material of screws | Steel | Manufacturer ID | 8021862 |
Specifications may be subject to change without notice
