vabm-b10-25-n12-4-p53
Product ID:15207
Updated: 2026/4/4
Key Features
- 1Maximize space with a 27.5 mm grid dimension. 2、Install flexibly with optional mounting positions. 3、Ensure durability with CRC 2 corrosion resistance. 4、Rely on strong wrought aluminum alloy material. 5、Connect easily with 1/2 NPT port compatibility.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Width dimension | 27.5mm | Mounting position | Any |
| Max. no. of valve positions | 4 | Corrosion resistance class (CRC) | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L | Product weight | 422g |
| Type of mounting | With mounting bracket | Pneumatic connection 1 | 1/2 NPT |
| Note on materials | RoHS-compliant | Manifold rail material | Wrought aluminum alloy |
| Manufacturer ID | 8026230 |
Specifications may be subject to change without notice
