Key Features
- 1Ensure precise valve positioning with the 12mm grid dimension. 2、Support up to 4 valve positions for multi-point control. 3、Withstand harsh environments using corrosion resistance class 0. 4、Secure installations with 0.6 Nm valve and 5 Nm wall torque. 5、Meet environmental standards with RoHS-compliant aluminum alloy.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Width dimension | 12mm | Max. no. of valve positions | 4 |
| Corrosion resistance class (CRC) | 0 - No corrosion stress | LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Max. tightening torque for valve mounting | 0.6Nm | Max. tightening torque for wall mounting | 5Nm |
| Product weight | 484g | Pneumatic connection 1 | G1/4 |
| Pneumatic connection 3 | G1/4 | Pneumatic connection 5 | G1/4 |
| Note on materials | RoHS-compliant | Manifold rail material | Wrought aluminum alloy |
| Manufacturer ID | 1361865 |
Specifications may be subject to change without notice
