vabs-k3-16s-20-m5-p
Product ID:183
Updated: 2026/4/3
Key Features
- 1Control fluid flow precisely for reliable operation. 2、Integrate easily with compact 12 mm design. 3、Ensure durability with wear-resistant construction. 4、Connect flexibly using M6 thread and side port. 5、Minimize leakage via EPDM diaphragm seal.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Size | 16 | Nominal width | 2mm |
| Valve size | 16mm | Fluid connector | Internal thread M5 |
| Mounting position | Any | Structural design | Connection direction at side |
| Max. no. of valve positions | 1 | Flow direction | Reversible |
| Operating medium | Liquid media Gaseous media | Information on operating and pilot media | Observe resistance of materials that come into contact with media |
| Corrosion resistance class (CRC) | 0 - No corrosion stress | LABS (PWIS) conformity | VDMA24364 zone III |
| Storage temperature | -20°C 70°C | For use in the food industry | See supplementary material information |
| Temperature of medium | 0°C 50°C | Ambient temperature | 0°C 50°C |
| Max. tightening torque for valve mounting | 0.3Nm | Max. tightening torque of pneumatic fitting | 0.5Nm |
| Max. tightening torque | 0.6Nm | Product weight | 9g |
| Sub-base mounting type | With through-hole | Pneumatic valve mounting type | With internal thread |
| Note on materials | RoHS-compliant | Material of sub-base | PEEK |
| Manufacturer ID | 8187601 |
Specifications may be subject to change without notice
