vabs-s7-be-b-g14-v14
Product ID:8037
Updated: 2026/7/4
Key Features
- 1Operate at 0.2-0.8 MPa for demanding pneumatic applications.
- 2Certify for ATEX zones 1, 2, 21, and 22 safety.
- 3Construct from ematal-coated aluminum with NBR seals.
- 4Achieve efficient airflow with 2.2 m³/h pressurization rate.
- 5Integrate easily with a compact 250-gram robust design.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Mounting position | Any | Pilot air supply port | Internal |
| Operating pressure | 2bar 8bar | Flow rate for piston valve pressurization | 2.2m3/h |
| Flow rate for piston valve exhausting | 8.6m3/h | Explosion prevention and protection | Zone 1 (ATEX) Zone 2 (ATEX) Zone 21 (ATEX) Zone 22 (ATEX) |
| Operating medium | Compressed air as per ISO 8573-1:2010 [-:-:-] | Corrosion resistance class (CRC) | 4 - Particularly high corrosion stress |
| LABS (PWIS) conformity | VDMA24364 zone III | Degree of protection | IP65 |
| Product weight | 250g | Type of mounting | With through-hole |
| Pneumatic connection 1 | G1/4 | Pneumatic connection 2 | Flange 1/4 NAMUR connection diagram |
| Pneumatic connection 3 | G1/4 | Note on materials | RoHS-compliant |
| Material of sub-base | Aluminum, ematal coated | Seals material | NBR |
| Manufacturer ID | 2999476 |
Specifications may be subject to change without notice
