vacn-n-a1-1
Product ID:15358
Updated: 2026/7/4
Key Features
- 1Operate reliably with 24V DC power for consistent performance.
- 2Consume only 0.7W of power for enhanced energy efficiency.
- 3Withstand harsh conditions with IP65 protection against dust and water.
- 4Meet strict environmental standards through full RoHS compliance.
- 5Enable continuous operation without downtime with a 100% duty cycle.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Actuation type | Electrical | Mounting position | Any |
| Duty cycle | 100% | Insulation class | F |
| Enameled wire insulation class | F | Coil characteristics | 24 V DC: 0.7 W |
| Permissible voltage fluctuations | +/- 10 % | Maritime classification | See certificate |
| Certificate issuing authority | DNV TAA000011J | Corrosion resistance class (CRC) | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B2-L | Degree of protection | IP65 |
| Ambient temperature | -20°C 60°C | Product weight | 95g |
| Electrical connection | Form A as per DIN EN 175301-803 | Type of mounting | With knurled nut |
| Note on materials | RoHS-compliant | Housing material | Polymer Steel |
| Material of pin contacts | Brass | Material of winding | Copper |
| Manufacturer ID | 8029144 |
Specifications may be subject to change without notice
