Key Features
- 1Deliver high vacuum performance for efficient industrial operations.
- 2Control processes easily with an integrated electric on-off valve.
- 3Ensure durability with a robust aluminum housing construction.
- 4Operate across a wide 1.5 to 8 BAR pressure range.
- 5Meet VDMA24364-B2-L and ISO 8573-1:2010 industry standards.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Nominal width of Laval nozzle | 1mm | Mounting position | Any |
| Ejector characteristics | High vacuum | Structural design | T-shape |
| Symbol | 00991482 | Operating pressure | 21.75psi 145psi |
| Max. vacuum | 80% | Operating medium | Compressed air as per ISO 8573-1:2010 [7:4:4] |
| Information on operating and pilot media | Operation with oil lubrication possible (required for further use) | LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Temperature of medium | -20°C 80°C | Ambient temperature | -20°C 80°C |
| Type of mounting | With through-hole | Pneumatic connection 1 | G1/4 |
| Pneumatic connection 3 | G1/4 | Vacuum connection | G1/4 |
| Housing material | Die-cast aluminum | Manufacturer ID | 9394 |
Specifications may be subject to change without notice
Still deciding on vad-1/4?
