vaem-s6-c-s6-r5
Product ID:11646
Updated: 2026/7/4
Key Features
- 1Support up to 12 monostable and 6 bistable pneumatic valves.
- 2Operate reliably on 24 V DC with +/- 10% voltage tolerance.
- 3Withstand harsh conditions with CRC 0 corrosion resistance.
- 4Achieve IP65 and NEMA 4 protection against dust and water.
- 5Integrate easily with 6 connections via a 5-pin M12 plug.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Max. no. of valve positions | 12 for monostable pneumatic valves 6 for bistable pneumatic valves | Max. residual current | 10A |
| Nominal operating voltage DC | 24V | Permissible voltage fluctuations | +/- 10 % |
| Corrosion resistance class (CRC) | 0 - No corrosion stress | LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Degree of protection | IP65 NEMA 4 | Ambient temperature | -5°C 50°C |
| Product weight | 200g | Number of electrical connections | 6 |
| Electrical connection | 5-pin M12 Plug | Housing material | PA |
| Manufacturer ID | 549048 |
Specifications may be subject to change without notice
