vasb-125-3/8-nbr
Product ID:2332
Updated: 2026/7/4
Key Features
- 1Ensure reliable pick-and-place with 1.5 convolutions for a secure grip.
- 2Reduce downtime using durable NBR material suited for industrial environments.
- 3Integrate seamlessly with existing Festo automation components and systems.
- 4Access comprehensive technical documentation for easy setup and maintenance.
- 5Optimize total cost of ownership with long service life and low maintenance.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Nominal width | 7mm | Suction cup diameter | 125mm |
| Effective suction cup diameter | 125mm | Connection position | Top |
| Symbol | 00991485 | Suction cup shape | Round bellows, 1.5 convolutions |
| Operating pressure | -13.775psi 0psi | Nominal operating pressure | -10.15psi |
| Operating medium | Atmospheric air based on ISO 8573-1:2010 [7:-:-] | LABS (PWIS) conformity | VDMA24364-A1-L |
| Ambient temperature | -20°C 80°C | Breakaway force at 70% vacuum | 606N |
| Holding force at nominal operating pressure | 606N | Mounting thread | G3/8 |
| Suction cup mounting | G3/8 | Vacuum connection | G3/8 |
| Color | Black | Shore hardness | 60 +/- 5 |
| Material of screwed plug | Die-cast zinc | Note on materials | RoHS-compliant |
| Suction cup material | NBR | Manufacturer ID | 152609 |
Specifications may be subject to change without notice
