Key Features
- 1Monitor adapter status in real-time with an LED signal display.
- 2Ensure compatibility using the 24V nominal DC operating voltage.
- 3Protect against dust and water ingress with robust IP65 rating.
- 4Resist moderate corrosion stress with CRC 2 durability.
- 5Install flexibly with optional mounting positions for easy integration.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Signal status display | LED | Nominal operating voltage DC | 24V |
| Corrosion resistance class (CRC) | 2 - Moderate corrosion stress | LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Degree of protection | IP65 as per IEC 60529 | Ambient temperature | -5°C 60°C |
| Mounting position | Any | Tightening torque | 0.25Nm |
| Product weight | 3.5g | Electrical connection | 3-pin/2-pin M8 / - Plug/socket |
| Protective earth connection | Not available | Type of mounting | On air solenoid valve with M2 central screw |
| Note on materials | RoHS-compliant | Housing material | PA |
| Material of pin contacts | Bronze | Manufacturer ID | 571686 |
Specifications may be subject to change without notice
