ysrw-7-10
Product ID:6989
Updated: 2026/7/19
Key Features
- 1Feature a self-adjusting cushioning system with a soft characteristic curve.
- 2Withstand moderate corrosion stress with a CRC 2 resistance classification.
- 3Mount in any position for flexible system design and installation.
- 4Achieve a quick 0.2-second reset time at room temperature.
- 5Utilize a compact 41mm body length for space-limited applications.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Size | 7 | Stroke | 10mm |
| Cushioning | Self-adjusting Soft characteristic curve | Mounting position | Any |
| Position sensing | None | Symbol | 00991495 |
| Max. impact velocity | 3m/s | Reset time at room temperature | 0.2s |
| Reset time at min. ambient temperature | 1s | Mode of operation | Pushing Single-acting |
| Corrosion resistance class (CRC) | 2 - Moderate corrosion stress | LABS (PWIS) conformity | VDMA24364-B2-L |
| Ambient temperature | -10°C 80°C | Cushioning length | 10mm |
| Max. stop force | 300N | Max. energy absorption per stroke | 2.5J |
| Max. energy absorption per hour | 15000J | Max. residual energy | 0.01J |
| Resetting force | 1.2N | Min. insertion force | 10N |
| Product weight | 18g | Load range | 5kg |
| Type of mounting | With lock nut | Note on materials | RoHS-compliant |
| Seals material | NBR | Housing material | High-alloy steel |
| Piston rod material | High-alloy steel | Manufacturer ID | 191193 |
Specifications may be subject to change without notice
