FBS 4-6 BU
Product ID:19004
Updated: 2026/8/2
Key Features
- 1Contains over 1,000 components including growth factors, hormones, and transport proteins.
- 2Supports the widest range of cell types, including both cell lines and primary cells.
- 3Promotes rapid and consistent cell growth, reducing the possibility of mammalian cells binding or lysing.
- 4Contains low levels of antibodies and other growth-inhibiting components, ensuring minimal interference in cell culture.
- 5Widely used in various applications including biopharmaceuticals, cell and gene therapy production, and vaccine production.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Product type | Jumper | Number of positions | 4 |
| Pitch | 6.2 mm | Article revision | 05 |
| Maximum load current | 32 A (The current values for the jumpers can deviate when used in different modular terminal blocks. The precise values can be found in the accessories data for the respective modular terminal blocks.) | Maximum load current | 32 A (The current values for the jumpers can deviate when used in different modular terminal blocks. The precise values can be found in the accessories data for the respective modular terminal blocks.) |
| Width | 23.1 mm | Height | 23 mm |
| Depth | 23 mm | Pitch | 6.2 mm |
| Color | blue (RAL 5015) | Material | Copper |
| Flammability rating according to UL 94 | V0 | Insulating material | PA |
| Ambient temperature (operation) | -60 °C ... 110 °C (Operating temperature range incl. self-heating; for max. short-term operating temperature, see RTI Elec.) | Ambient temperature (storage/transport) | -25 °C ... 60 °C (for a short time, no longer than 24 h, -60°C to +70°C) |
| Ambient temperature (assembly) | -5 °C ... 70 °C | Ambient temperature (actuation) | -5 °C ... 70 °C |
| Permissible humidity (operation) | 20 % ... 90 % | Permissible humidity (storage/transport) | 30 % ... 70 % |
| Mounting type | Plug-in mounting |
Specifications may be subject to change without notice
