FBSK 4-7,5
Product ID:22786
Updated: 2026/7/12
Key Features
- 1Fully Insulated Design: Ensures safe and reliable connections.
- 24 Positions: Perfect for applications requiring multiple connections.
- 37.5 mm Pitch: Compact design for efficient use in electronic systems.
- 4WEEE/RoHS Compliant: Meets environmental standards for sustainable use.
- 5High CTI Rating: Excellent insulation properties with a CTI rating of 600 according to IEC 60112.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Product type | Bridge | Product family | FBSK |
| Product line | COMBICON Terminals Special | Number of positions | 4 |
| Pitch | 7.5 mm | Number of connections | 4 |
| Number of rows | 1 | Number of potentials | 4 |
| Article revision | 03 | Pitch | 7.5 mm |
| Note | WEEE/RoHS-compliant, free of whiskers according to IEC 60068-2-82/JEDEC JESD 201 | Contact material | Cu alloy |
| Color (Housing) | red (3001) | Insulating material | PA |
| Insulating material group | I | CTI according to IEC 60112 | 600 |
| Flammability rating according to UL 94 | V0 | Glow wire flammability index GWFI according to EN 60695-2-12 | 850 |
| Glow wire ignition temperature GWIT according to EN 60695-2-13 | 775 | Temperature for the ball pressure test according to EN 60695-10-2 | 125 °C |
| Insulating material | PA | CTI according to IEC 60112 | 600 |
Specifications may be subject to change without notice
