FLKM 14/KDS3-MT/PPA/PLC/SC028
Product ID:20714
Updated: 2026/8/6
Key Features
- 114-Position Interface Module: Supports up to 14 positions for versatile connectivity.
- 28-Channel Capability: Designed for 8 channels with knife disconnect terminal blocks and test sockets.
- 3Durable Construction: Made with high-quality materials, ensuring reliability in harsh environments.
- 4Comprehensive Compatibility: Compatible with SIEMENS S7-1500, ABB S800 I/O, and other leading controllers.
- 5IP20 Protection: Offers degree of protection IP20, suitable for various industrial applications.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Product type | Interface module | Overvoltage category | II |
| Pollution degree | 2 | Nominal voltage U | 48 V AC/DC |
| Max. current carrying capacity per branch | 1 A | Max. total current of voltage supply | 3 A |
| Rated insulation voltage | 50 V | Rated surge voltage | 0.5 kV |
| Connection method | Screw connection with disconnect knife | Number of positions | 12 |
| Conductor cross section rigid | 0.2 mm² ... 4 mm² | Conductor cross section flexible | 0.2 mm² ... 2.5 mm² |
| Conductor cross section AWG | 24 ... 12 | Connection method | Flat-ribbon cable connector in acc. with IEC 60603-13 |
| Number of connections | 1 | Number of positions | 14 |
| Width | 67 mm | Height | 77 mm |
| Depth | 62 mm | Color | green (RAL 6021) |
| Housing insulation material | PVC | Ambient temperature (operation) | -20 °C ... 50 °C |
| Standards/regulations | DIN EN 50178 | Mounting position | any |
| Notes on operation | For proper use, the specifications of the installation directive (see Downloads) must be observed. For applications or use with third-party products, the specifications, and the safety and warning instructions of the respective third-party manufacturer must also be met. |
Specifications may be subject to change without notice
