FLKM-2FLK14/KDS3-MT/PPA/SC034
Product ID:22004
Updated: 2026/7/28
Key Features
- 114-Position Interface Module: Designed for complex industrial applications with 14 positions.
- 2Versatile Compatibility: Supports various controllers including Siemens S7-300 and ABB S800 I/O systems.
- 3Robust Insulation: Meets overvoltage category II and pollution degree 2 standards for reliable operation.
- 4High Current Capacity: Handles up to 1 A per branch with a total current of 3 A for voltage supply.
- 5Durable Construction: Built with PVC housing and suitable for ambient temperatures from -20°C to 50°C.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Product type | Interface module | Article revision | 04 |
| Insulation | Functional insulation | Overvoltage category | II |
| Pollution degree | 2 | Nominal voltage U | 60 V DC |
| Max. current carrying capacity per branch | 1 A | Max. total current of all branches | 3 A |
| Rated insulation voltage | 63 V | Rated surge voltage | 0.6 kV |
| Connection method | Screw connection with disconnect knife | Number of positions | 20 |
| Conductor cross section rigid | 0.2 mm² ... 4 mm² | Conductor cross section flexible | 0.2 mm² ... 2.5 mm² |
| Conductor cross section AWG | 24 ... 12 | Connection method | IDC/FLK socket strip |
| Number of connections | 2 | Number of positions | 14 |
| Status display present | No | Width | 113 mm |
| Height | 77 mm | Depth | 52.46 mm |
| Color | gray (RAL 7042) | Ambient temperature (operation) | -20 °C ... 50 °C |
| Standards/regulations | DIN EN 50178: 1998-04 | Mounting type | DIN rail mounting |
| Mounting position | any | Notes on operation | For proper use, the specifications of the installation directive (see Downloads) must be observed. For applications or use with third-party products, the specifications, and the safety and warning instructions of the respective third-party manufacturer must also be met. |
Specifications may be subject to change without notice
