FL SWITCH 4800E-P5B
Product ID:22173
Updated: 2026/7/28
Key Features
- 1Wide Input Voltage Range: Supports 90 V AC to 264 V AC and 88 V DC to 300 V DC for versatile power supply.
- 2IEC 61850 Compliance: Network structure meets IEC 61850 standards for reliable and efficient operation.
- 3High Reliability: Designed with a robust steel housing and IP20 protection for durability in harsh environments.
- 4Flexible Connectivity: Offers screw connection with solid and flexible conductor cross sections up to 6 mm².
- 5Versatile Applications: Ideal for FL SWITCH 48... managed switches, ensuring reliable power supply in various industrial settings.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Note on application | Only for industrial use | EMC note | EMC: class A product, see manufacturer's declaration in the download area |
| Product type | Power module | Input voltage | 115 V AC
230 V AC
110 V DC
250 V DC |
| Nominal input voltage range | 90 V AC ... 264 V AC
88 V DC ... 300 V DC | Input voltage range AC | 90 V AC ... 264 V AC |
| Input voltage range DC | 88 V DC ... 300 V DC | AC frequency range | 50 Hz ... 60 Hz |
| Connection method | Screw connection | Conductor cross section, rigid min. | 0.8 mm² |
| Conductor cross section, rigid max. | 6 mm² | Conductor cross section flexible min. | 0.8 mm² |
| Conductor cross section flexible max. | 6 mm² | Conductor cross section AWG min. | 18 |
| Conductor cross section AWG max. | 10 | Width | 151 mm |
| Height | 40 mm | Depth | 214 mm |
| Housing material | Steel | Degree of protection | IP20 |
| Ambient temperature (operation) | -40 °C ... 75 °C | Ambient temperature (storage/transport) | -40 °C ... 85 °C |
| Permissible humidity (operation) | 5 % ... 95 % (non-condensing) | Standards/specifications | IEC 61850 |
| Mounting type | Internal module for rack switch |
Specifications may be subject to change without notice
