FL SWITCH EP7428R-L3F1P
Product ID:22079
Updated: 2026/7/28
Key Features
- 1Ideal for streamlined setup in control panels with included brackets.
- 2Supports 10/100/1000 Mbps transmission speed for efficient data communication.
- 3Features 24 RJ45 or SFP ports for flexible network configurations.
- 4Designed with a robust polycarbonate fiber-reinforced housing for long-lasting performance.
- 5Operates in ambient temperatures from -40 °C to 85 °C and humidity levels of 5% to 95% (non-condensing).
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Width | 486.2 mm | Height | 44.4 mm |
| Depth | 446.7 mm | Note on application | Only for industrial use |
| Mounting type | Rack mount, includes brackets | Connection method | RJ45 |
| Note on the connection method | Auto negotiation and autocrossing | Transmission speed | 10/100/1000 Mbps |
| Transmission physics | Copper | Transmission length | 100 m (per segment) |
| No. of channels | RJ45 or SFP | Connection method | SFP |
| Transmission speed | 1000/10,000 Mbps (full duplex) | Transmission physics | Depending on the SFP module |
| Connection method | RJ45 | Transmission speed | 10/100/1000 Mbps |
| Transmission physics | Ethernet RJ45 | Output name | Alarm relay output: 24 V DC, 1 A maximum |
| Product type | Switch | Product family | Managed Switch EP7000 |
| Article revision | 00 | Overvoltage category | II |
| Degree of pollution | 2 | Basic functions | PoE according to IEEE IEEE 802.3af/IEEE 802.3at/IEEE 802.3bt |
| Signal contact control voltage | 24 V DC | Signal contact control current | 1 A |
| MAC address table | 16k | Basic functions | PoE according to IEEE IEEE 802.3af/IEEE 802.3at/IEEE 802.3bt |
| Maximum power dissipation for nominal condition | 60 W | Supply voltage | Based on modular power supplies used |
| Signal contact control voltage | 24 V DC | Signal contact control current | 1 A |
| Connection name | Power supply | Connection method | Screw connection |
| Conductor cross section, rigid | 0.2 mm² ... 2.5 mm² | Conductor cross section, flexible | 0.2 mm² ... 2.5 mm² |
| Conductor cross section AWG | 24 ... 12 | Degree of protection | IP20 |
| Ambient temperature (operation) | -40 °C ... 85 °C (Type tested to 85 °C for 16 hours) | Ambient temperature (storage/transport) | -40 °C ... 85 °C |
| Permissible humidity (operation) | 5 % ... 95 % (non-condensing) | Permissible humidity (storage/transport) | 10 % ... 95 % (non-condensing) |
| Vibration (operation) | in acc. with IEC 60068-2-6: 5g, 150 Hz | Standard designation | Ambient conditions |
| Standards/specifications | IEC 61850-3
IEEE 1613 | Conformance | CE-compliant |
| Noise immunity | IEC 61850-3, IEEE 1613, EN 61000-6-2: 2005 | Basic functions | PoE according to IEEE IEEE 802.3af/IEEE 802.3at/IEEE 802.3bt |
Specifications may be subject to change without notice
