PLC-RSC- 36DC/21
Product ID:17653
Updated: 2026/8/4
Key Features
- 1DIN Rail Mounting: Conveniently mount on DIN rail for easy installation in industrial settings.
- 224V DC Coil: Operates with a reliable 24V DC coil voltage for consistent performance.
- 3SPDT Configuration: Single-pole double-throw (SPDT) contact configuration for versatile switching applications.
- 46A Load Current Rating: Handles up to 6A of load current, making it suitable for various industrial loads.
- 5Silver Alloy Contacts: Features silver alloy contacts for high reliability and durability in harsh environments.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Product type | Relay Module | Product family | PLC-INTERFACE |
| Date of last data management | 20.04.2023 | Nominal input voltage U | 36 V DC |
| Minimum switching voltage | 5 V (at 100 mA) | Min. switching current | 10 mA |
| Connection method | Screw connection | Stripping length | 8 mm |
| Screw thread | M3 | Conductor cross section rigid | 0.14 mm² ... 2.5 mm² |
| Conductor cross section flexible | 0.14 mm² ... 2.5 mm²
0.2 mm² ... 2.5 mm² (Single ferrule)
2x 0.5 mm² ... 1.5 mm² (TWIN ferrule) | Conductor cross section AWG | 26 ... 14 |
| Tightening torque | 0.6 Nm ... 0.8 Nm | Width | 6.2 mm |
| Height | 80 mm | Depth | 94 mm |
| Flammability rating according to UL 94 | V0 (Housing) | Ambient temperature (operation) | -25 °C ... 60 °C |
| Ambient temperature (storage/transport) | -40 °C ... 85 °C |
Specifications may be subject to change without notice
