UMK- 1 OM-R/AMS
Product ID:18768
Updated: 2026/8/2
Key Features
- 1Integrated Diagnostic and Status Indicator: The UMK-1 OM-R/AMS includes a yellow LED status display for easy monitoring.
- 2Surge Protection: Equipped with surge protection and a polarity protection diode to safeguard against overvoltages.
- 3Solid-State Relay Compatibility: Can be fitted with solid-state relays for loads up to 350 V DC/1 A or 480 V AC/5 A.
- 4High Reliability: Operates at a 100% operating factor with components, ensuring consistent performance.
- 5DIN Rail Mounting: Designed for easy mounting on DIN rails with zero spacing, enhancing flexibility in installation.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Product type | Solid-state relay module | Operating mode | 100% operating factor |
| With components | yes | Article revision | 05 |
| Overvoltage category | III | Pollution degree | 2 |
| Rated surge voltage | 8 kV | Nominal input voltage U | 24 V DC |
| Input voltage range | 4 V ... 32 V | Typical input current at U | 2 mA (without plug-in module) |
| Protective circuit | Reverse polarity protection; Polarity protection diode
Surge protection; Suppressor diode | Status display/channel | Yellow LED |
| Contact switching type | 1 N/O contact (double contact) | Maximum switching voltage | 230 V AC
550 V AC |
| Minimum switching voltage | 24 V AC | Limiting continuous current | 5 A |
| Error detection (line break / short-circuit) | no | Connection method | Screw connection |
| Stripping length | 8 mm | Screw thread | M3 |
| Number of connections | 1 | Number of positions | 2 |
| Conductor cross section rigid | 0.2 mm² ... 4 mm² | Conductor cross section flexible | 0.2 mm² ... 2.5 mm² |
| Conductor cross section AWG | 24 ... 12 | Connection method | Screw connection |
| Stripping length | 8 mm | Screw thread | M3 |
| Number of connections | 1 | Number of positions | 2 |
| Conductor cross section rigid | 0.2 mm² ... 6 mm² | Conductor cross section flexible | 0.2 mm² ... 4 mm² |
| Conductor cross section AWG | 24 ... 10 | Status display present | Yes |
| Width | 22.5 mm | Height | 77 mm |
| Depth | 72 mm | Color | green (RAL 6021) |
| Housing insulation material | PVC, side panel PA non-reinforced, | Ambient temperature (operation) | -20 °C ... 60 °C |
| Ambient temperature (storage/transport) | -20 °C ... 70 °C | Standards/regulations | DIN EN 50178 |
| Mounting type | DIN rail mounting | Assembly note | in rows with zero spacing |
| Mounting position | any |
Specifications may be subject to change without notice
