UMK 22-REL 5/21
Product ID:17661
Updated: 2026/7/12
Key Features
- 1Compact size: 22.5 mm wide, 77 mm high, and 50 mm deep.
- 2High switching voltage: 250 V AC (30 V DC) with a minimum switching voltage of 5 V DC.
- 3Durable design: Operating temperature range from -20 °C to 65 °C.
- 4Reliable operation: Typical response time of 15 ms and typical release time of 5 ms.
- 5Versatile connections: Screw connection with stripping length of 7 mm for solid and flexible conductors.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| CE note | The products are offered exclusively for export outside the EU and the European Economic Area. | Product type | Relay Module |
| Application | Universal | Operating mode | 100% operating factor |
| Mechanical service life | 1x 10 | Date of last data management | 21.05.2024 |
| Test voltage (Winding/contact) | 5 kV (50/60 Hz, 1 min., winding/contact) | Nominal input voltage U | 5 V DC |
| Typical input current at U | 118.6 mA | Typical response time | 15 ms |
| Typical release time | 5 ms | Protective circuit | Freewheeling diode |
| Operating voltage display | LED | Contact switching type | 1 changeover contact |
| Contact material | AgCdO | Maximum switching voltage | 250 V AC (30 V DC) |
| Minimum switching voltage | 5 V (at 100 mA) | Limiting continuous current | 10 A |
| Min. switching current | 100 mA (At 5 V) | Connection method | Screw connection |
| Stripping length | 7 mm | Conductor cross section rigid | 0.14 mm² ... 2.5 mm² |
| Conductor cross section flexible | 0.14 mm² ... 1.5 mm² | Conductor cross section AWG | 30 ... 14 |
| Connection method | Screw connection | Stripping length | 7 mm |
| Conductor cross section rigid | 0.14 mm² ... 2.5 mm² | Conductor cross section flexible | 0.14 mm² ... 1.5 mm² |
| Conductor cross section AWG | 30 ... 14 | Width | 22.5 mm |
| Height | 77 mm | Depth | 50 mm |
| Color | green (RAL 6021) | Ambient temperature (operation) | -20 °C ... 65 °C |
| Ambient temperature (storage/transport) | -40 °C ... 85 °C | Assembly note | in rows with zero spacing |
| Mounting position | any |
Specifications may be subject to change without notice
