140ACO13000
Product ID:23744
Updated: 2026/7/14
Key Features
- 1Deliver precise 8-channel analog output with ±0.2% accuracy.
- 2Operate across a versatile 6-30V DC loop voltage range.
- 3Ensure rapid response with a fast 5 ms update time.
- 4Monitor system health with comprehensive fault signaling LEDs.
- 5Reduce energy costs with an efficient 5W power dissipation design.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Range of Product | Modicon Quantum automation platform | Product or Component Type | Analogue output module |
| Analogue output number | 8 | Addressing requirement | 8 output words |
| Loop voltage | 6…30 V DC | Maximum voltage drop | <30 V 25 mA |
| Analogue output range | 0...20 mA 0...20000 counts<br />0...25 mA 0...25000 counts<br />4...20 mA 0...16000 counts<br />4...20 mA 0...4095 counts | Absolute accuracy error | +/- 0.2 % of full scale 77 °F (25 °C) |
| Linearity | +/- 12 µA 4...20 mA 0...4095 counts<br />+/- 4 µA 0...20 mA 0...20000 counts<br />+/- 4 µA 0...25 mA 0...25000 counts<br />+/- 4 µA 4...20 mA 0...16000 counts | Accuracy drift according to temperature | 0.004 % of full scale/°C typical<br />0.007 % of full scale/°C maximum |
| Isolation between channels and bus | 1780 V for 1 minute AC | Update time | 5 ms |
| Setting time | 3.2 ms to +/-0.1% of the final value<br />1.6 ms to 5% of the final value | Fault type | Open circuit 4...20 mA |
| Bus current requirement | 550 mA | Maximum power dissipation in W | 5 W |
| External power requirement | 6...30 V | Marking | CE |
| Local signalling | for bus communication is present (Active) 1 LED (green)<br /> for external fault 1 LED (red)<br /> for channel is turned on 8 LEDs (green)<br /> for channel fault 8 LEDs (red) | Module format | Standard |
| Net Weight | 0.7 lb(US) (0.3 kg) | Product Certifications | cUL<br />FM Class 1 Division 2 |
| Standards | UL 508<br />CSA C22.2 No 142 | Resistance to electromagnetic fields | 9.1 V/m (10 V/m) 80…2000 MHz IEC 801-3 |
| Ambient Air Temperature for Operation | 32…140 °F (0…60 °C) | Ambient Air Temperature for Storage | -40…185 °F (-40…85 °C) |
| Relative Humidity | 95 % without condensation | Operating altitude | <= 16404.2 ft (5000 m) |
Specifications may be subject to change without notice
