In Stock

140CPS21400

Product ID:31679

Updated: 2026/7/15

Key Features

1Ensure stable operation with a 24 V DC input voltage range (20-30 V) and a 5.1 V DC output voltage.
2Support multiple devices with an 8 A summable output current for optimized power distribution.
3Protect connected devices with internal output overvoltage and overload protection.
4Minimize heat generation with calculated power dissipation for efficient operation.
5Receive immediate fault notification via an alarm output with a normally closed contact.

Need a quote? Enter your quantity and get pricing fast.

Qty

Detailed engineering parameters

Parameter	Value	Parameter	Value
Range of Product	Modicon Quantum automation platform	Product or Component Type	Power supply module
power supply type	Summable	Input voltage	24 V 20...30 V) DC
Input current	3800 mA	Inrush current	14 A 20 V<br />25 A 24 V
Maximum input power interruption	100 ms<br />1 ms 20 V	Associated fuse rating	5 A, slow-blow
Output voltage	5.1 V DC	Power supply output current	8 A summable
Output overvoltage protection	Internal	Output overload protection	Internal
Power dissipation	6 + (1.8 x Iout) where Iout is in A	Alarm output	1 NC 6 A 220 V power supply fault
Local signalling	for power (PWR OK) 1 LED (green)	marking	CE
Module format	Standard	Net Weight	1.43 lb(US) (0.65 kg)
Standards	CSA C22.2 No 142<br />UL 508	Product Certifications	cUL<br />FM Class 1 Division 2
Resistance to electrostatic discharge	4 kV contact IEC 801-2<br />8 kV on air IEC 801-2	Resistance to electromagnetic fields	9.1 V/m (10 V/m) 80…2000 MHz IEC 801-3
Ambient Air Temperature for Operation	32…140 °F (0…60 °C)	Ambient Air Temperature for Storage	-40…185 °F (-40…85 °C)
Relative Humidity	95 % without condensation	Operating altitude	<= 16404.2 ft (5000 m)

Specifications may be subject to change without notice
