140DDO35300
Product ID:28955
Updated: 2026/4/3
Key Features
- 1Achieve swift sub-1ms response for consistent process control. 2、Control 32 discrete outputs across 4 groups for extensive applications. 3、Withstand surges up to 56V for 1.3 seconds under demanding conditions. 4、Protect each group with a 5A fuse and blown fuse detection. 5、Monitor status via 32 green LEDs and a red fault indicator.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Range of Product | Modicon Quantum automation platform | Product or Component Type | Dc discrete output module |
| Discrete output number | 32 | Group of channels | 4 groups of 8 |
| Discrete output logic | Positive logic (source) | Addressing requirement | 2 output words |
| Discrete output voltage | 24 V DC | Output voltage limits | 19.2...30 V |
| Absolute maximum output | 56 V 1.3 s decaying pulse | Maximum voltage drop | <0.4 V 0.5 A |
| Maximum load current | 16 A per module<br />4 A per group | Surge current | 5 A 0.0005 s |
| Response Time | <= 1 ms at state 0 to state 1<br /><= 1 ms at state 1 to state 0 | Maximum leakage current | 0.4 mA 30 V |
| Load inductance | Inductance(H) = 0.5/((current(A))² x (switching frequency(Hz))) 50 Hz | Fault indication | Blown fuse<br />Loss of field power |
| Associated fuse rating | 3 A each point<br />5 A per group | Isolation between channels and bus | 1780 Vrms DC for 1 minute |
| Isolation between group | 500 Vrms DC for 1 minute | Protection Type | Internal output protection by 5 A fuse per group |
| Power dissipation | 1.75 W + (0.4 V x total module load current) | Marking | CE |
| Local signalling | for bus communication is present (Active) 1 LED (green)<br /> for external fault detected (F) 1 LED (red)<br /> for input status 32 LEDs (green) | Bus current requirement | 330 mA |
| Module format | Standard | Net Weight | 0.99 lb(US) (0.45 kg) |
| Product Certifications | GOST<br />BV<br />RMRS<br />ABS<br />DNV<br />GL<br />RINA<br />C-tick<br />FM Class 1 Division 2<br />safety certification non interfering | Standards | UL 508<br />CSA C22.2 No 142 |
| Resistance to electrostatic discharge | 4 kV contact IEC 801-2<br />8 kV on air IEC 801-2 | Resistance to electromagnetic fields | 9.1 V/m (10 V/m) 80…2000 MHz IEC 801-3 |
| Ambient Air Temperature for Operation | 32…140 °F (0…60 °C) | Ambient Air Temperature for Storage | -40…185 °F (-40…85 °C) |
| Relative Humidity | 95 % without condensation | Operating altitude | <= 16404.2 ft (5000 m) |
