140SDO95300S
Product ID:29827
Updated: 2026/7/15
Key Features
- 1Control 16 discrete outputs for versatile automation.
- 2Operate within a wide 19.2 to 30VDC voltage range.
- 3Ensure reliable performance with 2A surge current for 10ms.
- 4Meet global safety standards with CE, TÜV, CSA, and UL certifications.
- 5Integrate seamlessly into Modicon Quantum automation platforms.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Range of Product | Modicon Quantum automation platform | Product or Component Type | Safety dc discrete output module |
| Discrete output number | 16 | Group of channels | 1 |
| Discrete output logic | Positive logic (source) | Addressing requirement | 4 output words<br />7 input words |
| Discrete output voltage | 19.2...30 V DC | Absolute maximum output | 34 V |
| Maximum voltage drop | <0.3 V 0.5 A | Sensor power supply | 19.2…30 V |
| Maximum load current | <= 0.65 A each point<br /><= 10.04 A each group | Surge current | 2 A 10 ms |
| Response Time | <= 20 ms at state 0 to state 1<br /><= 20 ms at state 1 to state 0 | Maximum leakage current | 0.5 mA 30 V |
| Protection Type | With | Load inductance | Inductance(H) = 0.5/((current(A))² x (switching frequency(Hz)))<br />0.5 8 Hz |
| Fault indication | Channel fault<br />Overload<br />Power supply fault<br />System fault | Associated fuse rating | 10 A |
| Isolation between channels and bus | 1500 Vrms for 1 minute | Isolation between group and bus | 1500 Vrms for 1 minute |
| Power dissipation | 1.9 W + 0.65 I² | marking | CE |
| Local signalling | for bus communication is present (Active) 1 LED (green)<br /> for external fault detected (F) 1 LED (red)<br /> for output status 16 LEDs (green)<br /> for system failure, diagnostic of internal channel fault 16 LEDs (red) | Bus current requirement | 350 mA |
| Product Certifications | TÜV Rheinland (SIL2)<br />CSA<br />CSA HazLoc<br />UL<br />C-tick |
Specifications may be subject to change without notice
