ATV61HC11N4T1
Product ID:24139
Updated: 2026/7/14
Key Features
- 1Optimize fan and pump applications for exceptional performance.
- 2Customize settings to meet specific operational needs easily.
- 3Manage multiple pumps with ATV38 series compatibility.
- 4Enhance safety with Power Removal and ATEX compliance features.
- 5Configure settings via SoMove software on PC or mobile.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Asynchronous motor control profile | Variable torque standard | Device short name | ATV61 |
| Range of Product | Altivar 61 | Line Rated Current | 215 A |
| Cable entry | Type 1 conduit entry outdoor | communication port protocol | Modbus<br />CANopen |
| Impregnation material | Conformal coated | Input voltage | 400/480 V AC |
| Keypad Type | LCD keypad | Maximum Horse Power Rating | 150 hp |
| Motor power kW | 110 kW | Phase | 3 phase output<br />3 phase input |
| Output voltage | <= rated supply voltage | EMC filter | Class A EMC filter integrated |
| IP Degree of Protection | IP20 | NEMA Degree of Protection | No enclosure rating (open device) |
Specifications may be subject to change without notice
