HMIBUFND1P01
Product ID:30087
Updated: 2026/7/14
Key Features
- 1Equip a 3.4” monochrome LCD touchscreen with real-time clock.
- 2Support third-party protocols from Siemens, Omron, Mitsubishi, Allen-Bradley, and ABB.
- 3Build with a stainless steel front panel for 0-50°C operation.
- 4Include 16MB application memory and 128KB backup memory.
- 5Feature Ethernet and USB ports for seamless integration.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Range of Product | Harmony iPC | Product or Component Type | Operator dialogue terminal |
| Device short name | BOX PC Universal | Range Compatibility | Harmony iDisplay |
| compatibility code | BOX PC Universal | Processor name | Atom N270 1.66 GHz cache 512 KB |
| Chipset type | Intel 945GME | Video controller type | Intel Graphics Media Accelerator 950, 224Mb |
| Operating system | MS Windows XP Professional Edition SP3multi-language | Software package | Vijeo Designer run time demo |
| Data storage equipment | 60 GB Flash disk SSD MLC 2000000 h | Port Ethernet | 10BASE-T/100BASE-T/1000BASE-T |
| Memory description | 2 GB RAM DDR2 internal not expandable)<br /> SDRAM saved memory | Number of slots | 1 slot(s) for PCI |
| Type of cooling | Fanless | Integrated connection type | Ethernet TCP/IP 2 RJ45<br />DVI-I video port DVI-I<br />COM1 serial link male SUB-D 9 RS232C 115 kbauds<br />COM2 serial link male SUB-D 9 RS232C 115 kbauds<br />DVI-I video port (optional) DVI-I<br />COM3 serial link (optional) male SUB-D 10 RS232/422/485 115 kbauds<br />USB 2.0 port USB type A 480 Mbit/s front panel<br />USB 2.0 port 4 USB type A 480 Mbit/s top panel |
| [Us] rated supply voltage | 24 V DC power supply | Supply voltage limits | 18…30 V |
| Line Rated Current | 6 A | Inrush current | 7 A |
| Control type | ON/OFF push-button equipment ON and OFF)<br />Push-button reset) | Main type | Universal |
| Height | 10.6 in (270 mm) | Width | 10.2 in (260 mm) |
| Net Weight | 4.9 lb(US) (2.2 kg) | Standards | CSA C22.2 No 142<br /> ANSI/ISA 12-12-01<br /> UL 1604<br /> UL 508<br />Class I division 2 CSA C22.2 No 213 |
| Product certifications | CE<br />CULus<br />ATEX zone 22 dust<br />C-tick<br />GOST<br />GL | Pollution degree | 2 EN 61131-2 Ed.3 |
| Electromagnetic compatibility | Immunity to high frequency interference conforming to EN 61131-2 Ed.3 | Ambient air temperature for storage | -4…140 °F (-20…60 °C) IEC 60068-2-2 test Ab<br />-4…140 °F (-20…60 °C) IEC 60068-2-2 test Bb<br />-4…140 °F (-20…60 °C) IEC 60068-2-14 test Na |
| Relative Humidity | 10…85 % IEC 60068-2-30 test Db | Ambient air temperature for operation | 32…122 °F (0…50 °C) vertical installation) EN 61131-2 Ed.3 |
| Operating altitude | 6561.68 ft (2000 m) EN 61131-2 Ed.3 | Vibration resistance | 1.75 mm 2…9 Hz) continuous IEC 60068-2-6<br />3.5 mm 2…9 Hz) intermittently IEC 60068-2-6<br />0.5 gn 9…200 Hz) continuous IEC 60068-2-6<br />1 gn 9…200 Hz) intermittently IEC 60068-2-6 |
